BlueBird DR901 Slim Desktop UHF RFID Reader – USB-C, 710+ tags/s, Built-in Antenna
The BlueBird DR901 is an ultra-slim desktop UHF RFID reader, just 14 mm / 0.5 in thick, with an integrated circularly polarised antenna. It is designed for retail counters, back rooms and service desks in retail, healthcare, distribution and manufacturing. It connects by USB-C, with optional Ethernet, and reads more than 710 tags per second.
Key features
- Fits anywhere: an ultra-slim 220 x 261 x 14 mm pad that sits neatly on or under a counter.
- No extra antenna to buy: the circularly polarised antenna is built in.
- Controlled read zone: transmit power from 3 to 27 dBm, adjustable in 1 dBm steps, to limit cross-reading of nearby items.
- Simple connection: USB Type-C plug-and-play, with optional 10/100 Mbps Ethernet.
- Quick reads: more than 710 tags per second from EPC Class-1 Gen-2 V2 tags.
- Customer-facing design: a clean look suited to shop floors as well as back offices.
Specifications
| Dimensions | 220 x 261 x 14 mm (8.7 x 10.3 x 0.5 in) |
|---|---|
| Weight | 327.6 g / 11.6 oz |
| Power / interface | USB Type-C (optional Ethernet 10/100 Mbps) |
| Antenna | Integrated, circularly polarised |
| Sealing | IP42 |
| RFID protocol | EPC Class-1 Gen-2 V2 compliant |
| Transmit power | 3–27 dBm, adjustable in 1 dBm increments |
| Read rate | 710+ tags/sec |
| Read range | Up to 2.3 m / 7.5 ft (tag dependent) |
Ideal for
Retail checkout and returns counters, store back rooms, healthcare and pharmacy service desks, distribution dispatch points and manufacturing stations that verify or encode RFID tags. Its large, flat reading surface makes it practical to place folded garments, boxes or trays directly on the reader, while the adjustable power keeps reads limited to the counter. Where a cabled network is preferred, the optional Ethernet connection gives an alternative to USB.
Infinite Solutions is an authorized BlueBird partner. We supply BlueBird devices with configuration, MDM/BOS setup, accessories and support, and enquiries from India and international projects are welcome. Call/WhatsApp +91 93110 11467 or send an enquiry. See the full BlueBird range.
